MultiDelta
Delta (polygon) connection of multi phase systems consisting of multiple base systems
Library
Modelica/Electrical/MultiPhase/Basic
Description
Delta (polygon) connection of a multi phase circuit consisting of multiple base systems (see multi phase guidelines).
See also
Parameters
| Name | Label | Description | Data Type | Valid Values |
|---|---|---|---|---|
mo_m | m | Number of phases | Scalar | |
mo_mSystems | mSystems | Number of base systems | Scalar | |
mo_mBasic | mBasic | Phase number of base systems | Scalar |
Ports
| Name | Type | Description | IO Type | Number |
|---|---|---|---|---|
plug_p | implicit | input | 1 | |
plug_n | implicit | output | 1 |
